Package thermal oil boiler generally refers to small and medium capacity shop-assembled oil or gas thermal oil boiler. The capacity of package thermal oil boiler ranges from 120kW to 3500kW, i.e., from 100,000kcal/h to 3,000,000kcal/h. Thermal oil boiler manufacturer Taishan Group won an order from Poland, one 2300kW (2,000,000kcal/h) gas hot oil boiler.

Technical Data of Package Thermal Oil Boiler

Name: Organic heat carrier boiler

Model: YYW2300-Q

Rated heat power: 2300kW / 200x10⁴kcal/h

Working pressure: 0.8MPa

Design pressure: 1.1MPa

Rated oil supply temperature: 250℃

Rated oil return temperature: 220℃

Max temperature of medium: 320℃

Working medium: heat transfer oil

Medium capacity: 2.5m3

Medium circulation amount: 160m3/h

Fuel type: Natural gas

Lowering heating value: 8450kcal/Nm3 / 35356kJ/Nm3

Fuel consumption: 278Nm3/h

Design heat efficiency: 94.2%

Pipe diameter: 150mm

Installed power: 50kW

Dust emission: ≤20mg/m3

SO2 emission: ≤50mg/m3

NOx emission: ≤150mg/m3

Mercury and its compounds: 0mg/m3

Overall size: 5960x2830x2800mm

Transport weight: 11835kg

Technical Data of Package Thermal Oil Boiler Auxiliaries

Burner: Ecoflam Italy, hot air, BLU TS4000 PR, DN65, 7.5kW, 20-50kPa supply pressure

Circulating oil pump: model WRY125-80-250, flow 160m3/h, head 60m, power 45kW

Oil filling pump: model 2CY3.3/3.3-1, flow 3.3m3/h, pressure 0.32MPa, power 1.5kw

Y-type oil filter: model YG41-16C, size DN150

Oil-gas separator: model FL150

Expansion tank: volume 3.5m3

Oil storage tank: volume 8m3

Chimney: diameter 450mm, height 12m

So far, we have exported over thirty sets coal fired thermal oil boiler, biomass hot oil boiler, diesel and gas hot oil boilers abroad. The capacity ranges from 600kW to 7000kW, i.e., from 500,000 kcal/h to 6,000,000kcal/h.
